Integrated Systems Portfolio

AERIS-powered drones, interceptors, electronic warfare systems, and support infrastructure—designed to work seamlessly together.

Intelligence, Surveillance & Reconnaissance

BESTSELLER ASD-120 Micro ISR Drone

Micro ISR Drone

ASD-120 Series

Ultra-portable tactical surveillance platform optimized for stealth and rapid deployment. Backpackable design with industry-leading noise reduction for covert operations.

Key Specifications:

  • MTOW: 1.5 kg (3.3 lbs)
  • Payload: 300-500g modular bay
  • Endurance: 40 min (no payload), 32 min (350g payload)
  • Speed: 14 m/s cruise, 25 m/s max (90 km/h)
  • Range: 10 km LOS, 15 km with relay
  • Wind: 10 m/s continuous, 16 m/s gusts
  • Ceiling: 4,000m AGL / 6,000m MSL
  • Noise: 65 dB(A) at 5m (6 dB below standard)
  • Temperature: -20°C to +50°C operational
  • Weather: IP54 rated (rain resistant)

Standard Equipment:

  • EO: 4K 30fps with 3x optical zoom
  • Thermal: 640×512 @ 30Hz LWIR
  • GNSS: GPS L1/L2, GLONASS, Galileo, BeiDou
  • VIO: Stereo cameras + 200Hz IMU for GPS-denied
  • Comms: AES-256 encrypted mesh, frequency hopping
  • AI: NVIDIA Jetson Nano for onboard processing
  • Storage: 128GB onboard, hot-swappable SD
  • Battery: LiPo 4S 5200mAh, hot-swappable
  • Deployment: 90-second setup, foldable arms
  • Remote ID: FAA/EASA compliant broadcast
ASD-300 Medium ISR Drone

Medium ISR Drone

ASD-300 Series

Extended-endurance platform for persistent surveillance and multi-sensor missions. Hot-swappable batteries enable continuous 24/7 operations with automated docking.

Key Specifications:

  • MTOW: 8 kg (17.6 lbs)
  • Payload: 2.5 kg multi-sensor gimbal
  • Endurance: 60 min (1.5kg payload), 45 min (2.5kg)
  • Speed: 18 m/s cruise, 28 m/s max (100 km/h)
  • Range: 20 km LOS, 50 km with relay
  • Wind: 12 m/s continuous, 18 m/s gusts
  • Ceiling: 5,000m AGL / 7,000m MSL
  • Temperature: -30°C to +55°C operational
  • Weather: IP56 rated (heavy rain, dust)
  • Vibration: MIL-STD-810H compliant

Standard Equipment:

  • EO: 4K with 30x optical zoom, image stabilization
  • Thermal: 1280×1024 @ 30Hz cooled MWIR
  • LRF: Eye-safe laser rangefinder to 5km
  • GNSS: Multi-constellation with RTK option
  • VIO: Triple-redundant navigation system
  • Comms: Dual-band encrypted, MIMO antennas
  • AI: NVIDIA Xavier NX for advanced analytics
  • Storage: 1TB SSD with encryption at rest
  • Battery: Dual hot-swap 6S 16000mAh smart packs
  • Options: Spotlight, loudspeaker, drop mechanism

Counter-UAS Interceptors

CIVILIAN SAFE ID-200 Net Interceptor

Net Capture Interceptor

ID-200 SafeGuard

Non-kinetic drone capture system for civilian airspace. Reusable net deployment with VTOL recovery enables safe neutralization near crowds and airports.

Key Specifications:

  • Max Speed: 180 km/h (112 mph)
  • Intercept Range: 3 km effective radius
  • Flight Time: 20 minutes loiter
  • Capture Method: Deployable 4m² kevlar net
  • Recovery: VTOL with captured target
  • Guidance: EO/IR tracking + radar cuing
  • Success Rate: 94% against DJI-class targets
  • Reusability: Full system reusable
  • Launch: Vertical takeoff, no infrastructure
  • Safety: Parachute recovery if net deployed

Features:

  • Safe for use over populated areas
  • No explosive or kinetic risks
  • Automatic target size assessment
  • Multi-drone swarm intercept capable
  • Integration with ground radar systems
  • Real-time video feed during intercept
  • Compliant with civilian airspace rules
  • Training mode with simulated captures
ID-400 Kinetic Interceptor

Kinetic Interceptor

ID-400 SkyGuard

High-speed hard-kill interceptor for military point defense. Defeats loitering munitions and hostile drones through precise kinetic impact.

Key Specifications:

  • Max Speed: 450 km/h (280 mph) dash
  • Intercept Range: 5 km effective radius
  • Flight Time: 12 minutes at combat power
  • Propulsion: Hybrid electric + solid booster
  • Warhead: Hardened kinetic penetrator
  • Guidance: mmWave radar + EO terminal
  • Hit Probability: Pk 0.85 single shot
  • Launch: Tube or rail, 3-second ready
  • Salvo: 8-unit launcher available
  • G-limit: 12G maneuvering capability

Features:

  • All-aspect engagement capability
  • Fire-and-forget autonomous operation
  • Multi-target simultaneous engagement
  • Automatic target prioritization
  • Safe arming logic with multiple interlocks
  • Works in GPS-denied environments
  • Defeat of armored drone targets
  • Integration with C-RAM systems
  • NATO STANAG 4586 compatible

Electronic Countermeasures

PJ-200 Portable Jammer

Portable Drone Jammer

PJ-200 Portable

Man-portable counter-UAS jamming system. Creates protective RF shield forcing unauthorized drones to land or return home.

Key Specifications:

  • Effective Range: 2 km directional
  • Coverage: 60° cone or 360° bubble
  • Frequencies: 433/900 MHz, 2.4/5.8 GHz, GNSS
  • Power Output: 50W total (distributed)
  • Weight: 12 kg with battery
  • Runtime: 2 hours continuous
  • Setup Time: <60 seconds
  • Cooling: Active thermal management
SJ-400 Stationary Shield

Fixed-Site Jammer

SJ-400 Shield

Permanent installation for critical infrastructure protection. Automated threat response with comprehensive logging.

Key Specifications:

  • Effective Range: 5 km radius
  • Coverage: Dome or sectored
  • Power: 200W distributed array
  • Integration: Radar cuing capable
  • Control: Remote SOC operation
  • Mounting: Mast, roof, or tower
  • Weather: IP67, MIL-STD-810H
  • Compliance: FCC Part 15 certified

Support Systems & Accessories

TR-50 Tethered Relay

Tethered Relay Drone

TR-50 Persistent Eye

24/7 overwatch and communications relay. Ground-powered for unlimited endurance at 100m altitude.

  • • Unlimited flight time via ground power
  • • 100m tether with fiber optic data
  • • 50km relay range to swarm units
  • • Auto-launch/land in 30 seconds
  • • Survives 60 km/h winds
ADS-1 Autonomous Docking

Autonomous Docking Station

ADS-1 AutoBase

Weatherized charging dock enabling true 24/7 autonomous operations without human intervention.

  • • Precision landing with 5cm accuracy
  • • 20-minute fast charge to 80%
  • • Heated platform for winter ops
  • • Automatic battery conditioning
  • • Remote health monitoring
Modular Payload System

Modular Payload System

Quick-Release Modules

Hot-swappable sensor and equipment modules for mission flexibility. Change payloads in under 30 seconds.

  • • Multispectral imaging module
  • • CBRN detection sensors
  • • Cargo delivery box (5kg)
  • • Loudspeaker/spotlight combo
  • • LiDAR mapping scanner

Solution Bundles

Pre-configured packages optimized for specific missions with integrated AERIS platform support.

🚁

DFR Bundle

Complete Drone as First Responder package: ADS-1 dock + ASD-300 + AERIS Cloud + LTE/5G + CAD connector.

Learn More →
🛡️

Force Protection Bundle

Base defense package: Radar + AERIS Command + ID-200/400 interceptors + PJ-200 jammers.

Learn More →
🏟️

Critical Infrastructure Bundle

Stadium/airport protection: Multi-layer detection + no-fly enforcement + automated reporting.

Learn More →
🏥

Disaster Response Bundle

Rapid mapping and survivor location: Swarm ISR + thermal + mesh relay + emergency supply drop.

Learn More →

Configure Your System

Work with our team to design the optimal configuration for your mission requirements and budget.

Contact Us View Solutions
